Lab 3.4 - Execute an f5-newman-wrapper for Teardown

To get ready for the next module, we’re going to execute one last f5-newman-wrapper directly. This file will delete the framework and service we created in the last few labs. We’ve used a few f5-newman-wrapper files to create our service, and show some mutation, but for the deletion we will only use 1. As AS3 is declaration engine is a single call can be used to create a service and a single call can be used to remove it.

Task 1 - Execute f5-newman-build-5

  1. Navigate to the location containing the f5-newman-wrapper files cd /home/snops/f5-automation-labs/jenkins/f5-newman-build

  2. On BIG-IP A examine the virtual server module_3_vs, it should be active and Green:

    lab-3-1

  3. On BIGIP-A examine the pool module_3_pool, you should show 3 active members Green:

    lab-3-4

  4. f5-newman-build-5 contains the call to delete all items we’ve created in the last few modules

    Execute: f5-newman-wrapper f5-newman-build-5

    Output should look like:

     1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
    [root@f5-super-netops] [/home/snops/f5-automation-labs/jenkins/f5-newman-build] # f5-newman-wrapper f5-newman-build-5
[f5-newman-build-5-2018-07-30-08-06-14] starting run
[f5-newman-build-5-2018-07-30-08-06-14] [runCollection][Authenticate to BIG-IP] running...
newman

BIGIP_API_Authentication

❏ 1_Authenticate
↳ Authenticate and Obtain Token
  POST https://10.1.1.10/mgmt/shared/authn/login [200 OK, 1.62KB, 367ms]
  ✓  [POST Response Code]=200
  ✓  [Populate Variable] bigip_token=5EKXOKALEB2E7TALKKANCK6GUD

↳ Verify Authentication Works
  GET https://10.1.1.10/mgmt/shared/authz/tokens/5EKXOKALEB2E7TALKKANCK6GUD [200 OK, 1.44KB, 24ms]
  ✓  [GET Response Code]=200
  ✓  [Current Value] token=5EKXOKALEB2E7TALKKANCK6GUD
  ✓  [Check Value] token == 5EKXOKALEB2E7TALKKANCK6GUD

↳ Set Authentication Token Timeout
  PATCH https://10.1.1.10/mgmt/shared/authz/tokens/5EKXOKALEB2E7TALKKANCK6GUD [200 OK, 1.44KB, 83ms]
  ✓  [PATCH Response Code]=200
  ✓  [Current Value] timeout=1200
  ✓  [Check Value] timeout == 1200

┌─────────────────────────┬──────────┬──────────┐
│                         │ executed │   failed │
├─────────────────────────┼──────────┼──────────┤
│              iterations │        1 │        0 │
├─────────────────────────┼──────────┼──────────┤
│                requests │        3 │        0 │
├─────────────────────────┼──────────┼──────────┤
│            test-scripts │        3 │        0 │
├─────────────────────────┼──────────┼──────────┤
│      prerequest-scripts │        1 │        0 │
├─────────────────────────┼──────────┼──────────┤
│              assertions │        8 │        0 │
├─────────────────────────┴──────────┴──────────┤
│ total run duration: 1062ms                    │
├───────────────────────────────────────────────┤
│ total data received: 1.72KB (approx)          │
├───────────────────────────────────────────────┤
│ average response time: 158ms                  │
└───────────────────────────────────────────────┘
[f5-newman-build-5-2018-07-30-08-06-14] [runCollection][5 - Clean Up Service] running...
newman

f5-programmability-class-2

❏ 5 - Clean Up Service
↳ Step 1: Delete HTTP Application
  DELETE https://10.1.1.10/mgmt/shared/appsvcs/declare/ [200 OK, 1.2KB, 12s]
  ✓  [DELETE Response Code]=200
  ✓  [Current Value] results.0.message=success
  ✓  [Check Value] results.0.message regex /success|no change/

┌─────────────────────────┬──────────┬──────────┐
│                         │ executed │   failed │
├─────────────────────────┼──────────┼──────────┤
│              iterations │        1 │        0 │
├─────────────────────────┼──────────┼──────────┤
│                requests │        1 │        0 │
├─────────────────────────┼──────────┼──────────┤
│            test-scripts │        2 │        0 │
├─────────────────────────┼──────────┼──────────┤
│      prerequest-scripts │        1 │        0 │
├─────────────────────────┼──────────┼──────────┤
│              assertions │        3 │        0 │
├─────────────────────────┴──────────┴──────────┤
│ total run duration: 12.3s                     │
├───────────────────────────────────────────────┤
│ total data received: 273B (approx)            │
├───────────────────────────────────────────────┤
│ average response time: 12s                    │
└───────────────────────────────────────────────┘
[f5-newman-build-5-2018-07-30-08-06-14] run completed

    Note

    Notice the 200 OK responses, as it completed successfully

  5. On BIG-IP A the Partition, Virtual module_3_vs and Pool module_3_pool are deleted
